Structure / Basic Finishes

RCC Framed Structure with high quality AAC blocks for external and internal partitions, plastered and finished with cement paints externally.

Internal Painting with Acrylic Tractor Emulsion after application of two Coats of Putty and Primer. Paint will be Asian or equivalent.

The Height of each floor will be 10 feet maximum so the distance between the finished floor level and the finished inner roof level will be about 9’7”.

The Lintel Level will be 7 feet above the finished floor level.

Lofts in Kitchen and Master bedroom will be provided.

Swing hook will be provided if required by the customer.

Flooring /Staircase

Vitrified Tiles (2 Feet X 2 Feet) of RAK/Kajaria/NITCO make or equivalent for all areas except Bath rooms and Balconies which will have antiskid ceramic (RAK/Kajaria/NITCO or equivalent make) flooring (1 Feet X 1 Feet Dimension).

Staircases and Lobbies to be laid with Granite Tiles.

Doors

Polished teak wood door panel and frame for main entrance. Width of the door opening will be 7’ X 3’6’’. Main door will have appropriate hardware such as Godrej Ultra Locks, Heavy Duty Hinges etc.,

All Internal Doors will be provided with Seasoned Country wood frames with suitable hinges, tower bolts and good quality locks.

Flush doors for Internal Doors of size 7’X3’, Water Resistant Wooden Doors for Toilets with good quality locks and hard ware.

French Doors to be sliding/ openable UPVC type.

Windows

UPVC Single Glazed Swing Open type Windows / Sliding windows with Steel Grills wherever necessary.

UPVC Ventilators for the Toilets with Steel Grills.

Kitchen

Granite Platform 2 Feet Wide for Kitchen Counter for a minimum running length of 10 feet with Stainless Steel Sink with Drain board of minimum dimensions1000 mm X 600 mm of Carysil or equivalent make.

The Kitchen Platform should be able to accommodate the Sink/Cooking Stove/All Appliances comfortably.

Toilets

WC and Washbasin in all Bathrooms will be from Parryware or equivalent.

Suitable color Design Glazed tiles for the wall dado up to full height of wall.

Suitable color matching tile for the flooring. Tiles will be of RAK/Kajaria/NITCO make or equivalent.

Geyser provision with hot and cold water piping with high quality chrome plated pipe fittings.

CP Fittings to be of Jaquar make or equivalent.

All tap off points for wash basin tap, Geyser water point, etc. through angle

Water Supply

Deep Bore Well for Ground Water

Two compartment Underground Sump of capacity 30,000 litres for both metro water and ground water storage.

Ground Water will be tested and appropriate water treatment /filtration system would be installed based on the test results.

1 No RCC Overhead Water Tank will be installed on the terrace of capacity 15,000 Liters. It will be of two compartments to cater for storage of metro water (for Kitchens) and treated ground water (For all other areas). Piping system cross connections will also be provided to enable interchangeability or common use of Metro and or bore well water

Electrical

3 Phase Electric Connections.

3Ph X 10/30amp power supply meter with ELCB. Individual 3Ph DB inside each flat with lighting and power circuits segregated.

Multi-core high quality copper wiring in concealed PVC conduits with MCB and recessed switches.

Wiring will be of Finolex or equivalent make multi strand copper with 1.5 sq.mm for 5A circuits and 2.5 sq.mm for 15A power circuits.

High power Circuit for AC, Geyser, Fridge etc., and low power circuits for other points wherever required.

Modular plated Switches to be provided of GM Switches / Legrand or equivalent as per the table shown below.
