Structure

• RCC Framed Structure. 9" thk Red Brickwork for External Walls & 41/2" thk for Internal Walls. Designed for Seismic Zone - 3
• Plinth height - 1'6" from Driveway level. Floor to Roof top (incl slab) - 10'0". Lintel height shall be 7'-0" from FFL.
• Loft will be provided any one side in all bed rooms & Kitchen Preferably above the Entry.
2. Joinery • Main Door : Teak wood frame with solid designed panelled door including safety latch & magnetic catcher. All Hardwares shall be in Brass finish.
• Bed room Doors : Country Wood Frame with compressed door finished with Laminate including magnetic catcher. All Hardwares in SS Finish.
• Toilet : Country Wood Frame with Flush Door Shutter with Laminate on one side PU Coated on other side. All hardwares in SS Finish.
• Terrace : Country Wood Frame with Flush Door Shutter with PU Coat on both sides . All hardwares in SS Finish.
• Windows / French Windows : UPVC - Openable Windows with Clear Glass & Grill
• Ventilator : UPVC Louvers with Pin Headed Glass.
• French Door : C.W.Framed with Glazed Shutter with grills
• Grills : For all French Windows & Windows - 12 mm sq. rod with std design Handrails
• Staircase handrail : S.S Hand rail - As per Architect's Design
• Balcony handrail : MS Hand rail - As per Architect's Design / Elevation 4. Flooring
• Entrance Veranda / Steps : Granite Flooring
• Staircase : Granite Flooring with 4" high skirting
• Living, Dining & Bedrooms : 210"x 2'0" Vitrified Tile flooring with 4" high skirting.
• Kitchen : 2'0"x 2'0" Vitrified Tile flooring of Mat finish With 4" high Skirting 20mm thk G20 Polished Granite top for Kitchen platform
• Balcony : 12"x I - Anti Skid Tile flooring with 4" high skirting . Toilet / service : 12"x 12" - Anti Skid Tile flooring • Car Parking : Eurocon Tile flooring
5. Dadoing . Toilet : Glazed Ceramic Tile dado up to 7'0" Height • Kitchen : Glazed Ceramic Tile Dado Tile upto Lintel Height fro Cooking Platform . Dining : Glazed tile dado for 2' ht above Washbasin
6. Painting
• Ceiling : 2 coats of Emulsion over I coat of Primer and putty (Premium). . Inner Walls finish : 2 coats of Emulsion over I coat of primer & 2 coats of Putty (Premium).
• Exterior Walls : 2 Coats Exterior Emulsion over one coat of Primer (Protech)
• Main Door : Melamine Matt Finish Polish.
• All other Doors : Enamel Paint Over Putty & Primer
• Grills : Two coat Enamel Paint over One coat of Primer
• Power supply : 3 phase power supply connection
• Safety device : MCB & ELCB (Earth leakage Circuit braker)
• Wires : Fire retardant Low smoke copper wire of a quality IS brand Polycab or equivalent will be provided
• Switches & sockets : Modular box , Modular switches & sockets of approved brand.
• HOB point : Point provided in the kitchen
• Light points : Sufficient Light points and Power Sokets will be provided in all rooms.
• TV & Data Points : TV& Cat-6 cable for Data Points Provision for all Bed Rooms & Living . Split AC : Split AC Provision for Living & all Bed Rooms
• Fridge : Fridge Provision in Kitchen or Dining. Inverter provision : Wiring for light and fan points
• Exhaust fan : Exhaust Provision for all Toilets & Kitchen 3. Sanitation & Plumbing
• Kitchen : SS Sink(Single bowl). Provision for Water purifier.
• Dining : Wall mounted Wash Basin with necessary fittings. . Toilet : Wash basin in in all toilets, Wall-mounted EWC with concealed tank & two in one tap with health faucet, diverter & Over head shower. Geyser Provision with hot & cold piping provision
• Sanitary Fittings : Parryware / Jaguar / Hindware or Equivalent
• CP fittings : Parryware / Jaguar or Equivalent
