1. STRUCTURE

Structural System: RCC framed structure designed to be seismic compliant (Zone 2).

Masonry: 200mm for external walls & 100mm for internal walls.

Floor-Floor height (incl. slab): 3200mm.

ATT: Anti-termite treatment will be done.

2. WALL/CEILING FINISH

Internal walls: Finished with 2 coats of putty, 1 coat of primer & 2 coats of premium emulsion.

Ceiling: Finished with 2 coats of putty, 1 coat of primer & 2 coats of tractor emulsion.

Exterior walls: Finished with 1 coat of primer & 2 coats of exterior emulsion paint with a color as per the architect’s design.

Bathroom: Vitrified tiles of size 600x1200mm up to 2500mm height & above will be finished with a coat of primer.

Kitchen: Will be left open for a modular kitchen.

Bathroom ceiling: Panel & Grid type false ceiling.

3. FLOOR FINISH WITH SKIRTING

Foyer, Living, Dining & Passage: Vitrified tiles of size 1200x600mm.

Bedroom, Kitchen & Mudroom: Vitrified tiles of size 600x600mm.

Bathrooms: Anti-skid ceramic tiles of size 600x600mm.

Balcony: Wooden finish tiles of size 600x1200mm.

Door threshold: Granite threshold will be provided for all doors.

4. KITCHEN & DINING

Kitchen: Will be left open for a modular kitchen.

Electrical point: For chimney, Hob & water purifier. A dish washer point will be provided wherever applicable.

Dining: Granite countertop wash basin with 300mm height Granite back splash.

5. BALCONY

Handrail: MS handrail as per the architect’s design. Sill level will be finished with Granite.

Cloth drying Hanger: A ceiling cloth drying hanger will be provided in the living balcony.

6. BATHROOMS

CP fittings & Sanitary fixtures: Jaquar or equivalent.

One of the Bathrooms: Wall-mounted WC with cistern, health faucet, single lever diverter, overhead shower, hand shower, foldable seater, spout, granite counter top wash basin and a 2' long trench drain.

Other Bathrooms: Wall-mounted WC with cistern, health faucet, single lever diverter, overhead shower, spout, granite countertop wash basin and a 2' long trench drain.

7. JOINERY

A. DOORS

Main door: Full jambs polished frame and architrave with a good quality double-sided veneer finish shutter of size 1200 x 2400mm. Ironmongeries include:

Digital door lock of Yale or equivalent.

18” tower bolts.

Door viewer.

Magnetic door catcher.

Concealed automatic door closure.

Bedroom doors: Full jamb architrave with a double-sided laminated designer shutter of size 1000 x 2400mm. Ironmongeries include:

Godrej or equivalent lock.

Magnetic door catcher.

Tower bolt, etc.

Bathroom doors: Granite finish full jamb architrave with a double-sided laminated designer door of size 800 x 2400mm. Ironmongeries include:

Thumb-turn lock of Godrej/equivalent without key.

Door bush, etc.

B. WINDOWS

Windows: Aluminum windows with sliding shutter with see-through Tinted glass & MS railing on the inner side (wherever applicable). Sill level will be finished with Granite.

French doors: Aluminum sliding shutters with tinted glass.

Ventilators: Aluminum framed fixed louvers / openable shutter for ODU access (wherever applicable). Soffit will be finished with Granite.

8. ELECTRICAL POINTS

Power supply: Single phase for 1 BHK, three phase for 2, 3 & 4 BHK.

Safety device: MCB (Miniature Circuit Breaker) & RCCB (Residual Current Circuit Breaker).

Switches & sockets: Modular box, modular switches & sockets of good quality IS brand.

Wires: FRLS (Flame Retardant Low Smoke) copper wire of a good quality IS brand.

Master control switch: Point in living / Foyer.

Foot lamp: Point in all bedrooms.

TV: Point in Living & all bedrooms.

Data: Point in Living & one of the bedrooms.

Split-air conditioner: Point in Living/Dining & all bedrooms.

Geyser: Point in all bathrooms.

Back-up: 350W for 1BHK, 400W for 2BHK, 500W for 3BHK, 650W for 4BHK.

SPECIFICATIONS COMMON TO BUILDING COMPLEX

COMMON FEATURES

Lift: Elevators of 10 passengers automatic lift will be provided.

Back – up: 100% Power backup for common amenities such as clubhouse, lifts, STP, WTP & common area lighting.

Owner’s directory: Apartment owner’s name directory will be placed on the ground floor.

Lift fascia: Designer Vitrified tile finish with granite jambs.

Lift lobby: Designer Vitrified tile finish with pattern.

Corridor: Vitrified tile finish of size 600x600mm.

Staircase floor: Granite flooring at the first 4 levels & tile flooring at other levels.

Staircase handrail: MS handrail with enamel paint finish.

Terrace floor: Pressed tile flooring.

Terrace doors: Good quality FRP door of size 900x2100mm with paint finish. Ironmongeries include:

Thumb-turn lock of Godrej or equivalent.

Door bush.

Door closer etc.

OUTDOOR FEATURES

Water storage: Centralized UG sump with WTP (Min. requirement as per water test report).

Rain water harvest: Rain water harvesting system as per site requirement.

STP: Centralized Sewage Treatment plant.

Safety: CCTV surveillance cameras will be provided all-round the building at pivotal locations on the ground floor.

Walkway: Walkway spaces will be well-defined as per the landscape’s design intent.

Security: A security booth will be provided at the project entry/exit facilitated with My Gate app.

Compound wall: The site perimeter will be fenced by a compound wall with entry gates for a height of 1800mm (as per design intent).

Landscape: Suitable landscape at appropriate places as per the landscape’s design intent.

Driveway: A convex mirror will be provided for safe turning at the driveway in / out.

External Driveway: Interlocking paver block/equivalent flooring with a demarcated driveway as per the landscape’s design intent. Granite / Cobble stone flooring will be provided in the entrance driveway and block lobby entrances.
