Specifications of Casagrand Hola ChennaiStrucutre

STRUCTURAL SYSTEM RCC – Framed Structure designed for seismic compliant (Zone 3)

MASONRY – 200mm for external walls & 100mm for internal walls

FLOOR-FLOOR HEIGHT (INCL. SLAB) – Will be maintained at 2950mm

STRUCTURAL SYSTEM RCC Framed structure designed for seismic compliant (Zone 3)

MASONRY 200mm for external walls & 100mm for internal walls

FLOOR- FLOOR HEIGHT (INCL. SLAB) Will be maintained at 3300mm ATT Anti–termite treatment will be done

WALL FINISH

INTERNAL WALLS Finished with 2 coats of putty, 1 coat of primer & 2 coats of premium emulsion

CEILING Finished with 2 coats of putty, 1 coat of primer & 2 coats of tractor emulsion

EXTERIOR WALLS Exterior faces of the building finished with 1 coat of primer & 2 coats of exterior Emulsion paint with color as per architect design

BATHROOM Matte/Glazed ceramic wall tile of size 600x1200mm for a height of 2400mm.

TOILET CEILING Panel/Grid False ceiling

INTERNAL WALLS Finished with 2 coats of putty, 1 coat of primer & 2 coats of premium emulsion

CEILING Finished with 2 coats of putty, 1 coat of primer & 2 coats of tractor emulsion

EXTERIOR WALLS Finished with 1 coat of primer & 2 coats of exterior Emulsion paint with color as per architect design intent

BATHROOM Matte/Glazed ceramic wall tile of size 600x1200mm will be finished up to ceiling.

FLOOR FINISH WITH SKIRTING

FOYER, LIVING, DINING & INTERNAL PASSAGE Marble flooring

BEDROOMS & KITCHEN Vitrified tiles of size 600x1200mm

ALL BATHROOM Anti-skid ceramic tiles of size 600x600mm

BALCONY Vitrified tile of size 600x600mm

PRIVATE OPEN TERRACE (IF APPLICABLE) Vitrified tile of size 600x600mm

FLOOR FINISH WITH SKIRTING LIVING, DINING, KITCHEN & INTERNAL PASSAGE Marble flooring

BEDROOMS, FIRST FLOOR LOUNGE & STORE ROOM Vitrified tiles size of 600 x 1200 mm

BATHROOMS Anti-skid ceramic tiles of size 600x600mm

BALCONY Wooden deck finish tiles

OPEN TERRACE (FIRST FLOOR)

Wooden deck finish tiles

CAR PARKING Kota / Shahabad / outdoor tiles finish

TERRACE Pressed tiles finish

KITCHEN AND DINNING

KITCHEN Will be left open for modular work with electrical points & plumbing provisions

ELECTRICAL POINT For chimney & water purifier

DINING Granite counter mounted wash basin and wall dado of height 200mm

KITCHEN Will be left open for modular work with

electrical points & plumbing provisions

ELECTRICAL POINT For chimney & water purifier

BALCONY

HANDRAIL MS handrail as per architect’s design

CLOTH DRYING HANGER Ceiling cloth drying hanger rods provided in recommend location

HANDRAIL MS handrail as per architect’s design

BATHROOMS

SANITARY FIXTURE American standard or Equivalent

CP FITTINGS American standard or Equivalent

ATTACHED BATHROOMS Wall mounted WC with cistern, flush plate and Health faucet, Single lever diverter, Rain shower, hand shower and spout with Fixed glass partition, granite counter mounted wash basin and 2’ long trench drain

COMMON BATHROOMS Wall-mounted WC with cistern, flush plate and Health faucet, Single lever diverter, Overhead shower with fixed glass partition & spout with granite counter mounted wash basin and square designer drain

SANITARY FIXTURE Kohler or Equivalent

CP FITTINGS Kohler or Equivalent

BATHROOM 1 Wall mounted WC with cistern, flush plate and Health faucet, Single lever diverter, Rain shower, hand shower and spout with Fixed glass partition, granite counter mounted wash basin and 2’ long trench drain

BATHROOM 2,3 & 4 Wall-mounted WC with cistern, flush plate and Health faucet, Single lever diverter, Overhead shower & spout with Fixed glass partition, granite counter mounted wash basin and square designer drain

JONIERY

MAIN DOOR Good quality door frame with Veneer finish full jamb architrave and double sided veneer finish door of size 1200 x 2300mm Ironmongeries like Digital lock system of Yale or equivalent lock, door viewer, safety latch, magnetic catcher, etc.

BEDROOM DOORS Good quality Full jamb wooden door frame with laminate finish with double-sided laminate finish door of size 900 x 2300mm Ironmongeries like YALE or equivalent lock, door handle , door stopper, door bush / magnetic catcher etc.,

BATHROOM DOORS Good quality door frame with double-sided laminate finish door of size 800 x 2300mm Ironmongeries like Yale OR equivalent lock, door handle, door bush etc.,

UTILITY DOOR Good quality aluminium door of size 800 x 2300mm

WINDOWS Powder coated Aluminum windows with sliding shutter with see-through toughened glass and MS grill/railing (wherever applicable) Sill coping with granite

FRENCH DOORS Powder coated Aluminum frame and doors with toughened glass (wherever applicable) and without grill

VENTILATORS Powder coated Aluminum frame of fixed louver / open-able shutter for ODU access (wherever applicable) Sill and Soffit coping with granite

MAIN DOOR

Marble finish full jamb architrave and concealed hinges with double sided veneer finish door of size 1200 x 2400mm

Ironmongeries like Digital lock system of DormaKaba or equivalent lock, door viewer, safety latch, magnetic catcher, etc.

EDROOM DOORS

Good quality door frame with laminate finish Full jamb wooden architrave with double sided laminate finish door of size 1000x2400mm

Ironmongeries like DormaKaba OR equivalent lock, door stopper, door bush, door handle, magnetic catcher, etc.,

BATHROOM DOORS

Good quality door frame with double-sided laminate finish door of size 900 x 2400mm

Ironmongeries like DormaKaba OR equivalent lock, door handle, door bush etc.,

STORE ROOM DOOR

Good quality door frame with double-sided laminate finish door of size 750 x 2100mm

Ironmongeries like Yale OR equivalent lock, door handle, door bush etc.

TERRACE DOORS

Good quality door frame with FRP shutters of size 900 X 2100mm with paint finish. Ironmongeries like thumb turn lock of Yale or equivalent.

ELECTRICAL POINT

POWER SUPPLY 3 PHASE power supply connection SAFETY DEVICE MCB & RCCB (Residual Current Circuit breaker)

SWITCHES & SOCKETS Honeywell or equivalent will be provided

WIRES Fire Retardant Low Smoke (FRLS) copper wire of a quality BIS brand polycab or equivalent will be provided

FOOT LAMP In all bedrooms.

5 AMP SOCKET(OUTDOOR) Point provided in the living balcony in recommended location. FAN Point provided in kitchen and Living balcony (wherever applicable) TV Point in Living & any one bedroom and provision in other bedrooms

DATA Point in Living & any one bedroom

SPLIT- AIR CONDITIONER Points will be given in living / Dining and in all bedrooms

EXHAUST FAN Exhaust fan point will be provided in all bathrooms

GEYSER Geyser point will be provided in all bathrooms

BACK-UP 350W for 1BHK, 400W for 2BHK, 500W for 3BHK & 650W for 4BHK

POWER SUPPLY 3 PHASE power supply connection

SAFETY DEVICE MCB & RCCB (Residual Current Circuit breaker)

SWITCHES & SOCKETS Honeywell or equivalent will be provided

WIRES Fire Retardant Low Smoke (FRLS) copper wire of good quality IS brand

VIDEO DOORBELL Provided in the entrance – Main door

5 AMP SOCKET (OUTDOOR) Point provided in the balcony (wherever applicable)

FOOT LAMP Provided in all bedrooms

FAN Point Provided in kitchen and balcony

TAP Provided in the outdoor deck.

TV Point in Living & any one bedroom and provision in other bedrooms & lounge.

DATA Point in Living & any one bedroom

SPLIT- AIR CONDITIONER Points in living/dining, lounge & all Bedrooms

EXHAUST FAN Exhaust fan Point will be provided in all bathrooms

GEYSER Point will be provided in all bathrooms

VILLA BACK-UP Inverter provision for all room fan and light points

COMMON FEATURES

WATER STORAGE Centralized UG sump with WTP (Min. requirement as per water test report)

RAIN WATER HARVEST Rain water harvesting site

STP Centralized Sewage Treatment plant

SAFETY CCTV surveillance cameras will be provided all-round the building at pivotal Locations in ground level

WELL DEFINED WALKWAY Walkway spaces well defined as per landscape design intent

SECURITY Security booth will be provided at the entry/exit facilitated with MY GATE App

COMPOUND WALL Site perimeter fenced by compound wall with entry gates for a height of 1500mm and over that 300mm with barbed fence and Featured compound wall (wherever applicable) as per design intent

LANDSCAPE Suitable landscape at appropriate places in the project as per intent

DRIVEWAY Convex mirror for safe turning in driveway in / out

EXTERNAL DRIVEWAY Stamped concrete/Interlocking paver block / or equivalent flooring with demarcated driveway as per landscape design intent Granite/Cobble stone flooring finish in entrance driveway and block lobby entrances
